Number of turns (per coil): 12
Maximum Coil Current: 60 A, 5 min.
Nominal Coil Current: 30 A continuous
Coil Spacing: 200 mm, 250 mm, 300 mm
(the following data corresponds to a coil spacing of 200 mm)
Maximum Magnetic Field Strength: 2500 A/m, 5 min.
Nominal Magnetic Field Strength: 1288 A/m continuous
Magnetic Field Strength, 1 A Coil Current: 42.93 A/m, 152.66 dBμA/m
Current required for 1 A/m: 23.29 mA
Conversion Current–Field Strength: 32.66 dB/m
Coil diameter: 400 mm
Mechanical Dimensions: 0.38 m × 0.58 m × 0.42 m
Terminals: 4 mm female with universal wire fixture
Usable Frequency Range: DC – 500 kHz
Inductance (per coil): 120 µH
Inductance (pair of coils): 240–260 µH
Resistance (per coil): 47.5 mΩ
Coil Capacitance (pair of coils): 35 pF
Resonant Frequency (pair of coils): > 1.4 MHz
Weight: 10.2 kg
