Number of turns (per Coil): 81
Maximum coil current: 6 A, 5 min.
Nominal continuous coil current: 4 A
Coil spacing for best field homogeneity: 132 mm
Coil spacing for high field strengths (all following values refer to 116 mm coil distance): 116 mm
Maximum magnetic field strength: 3000 A/m, 5 min.
Nominal continuous magnetic field strength: 2000 A/m
Magnetic field strength @ 1 A Coil Current: 500 A/m
Current required for 1 A/m: 2 mA
Conversion Current–Fieldstrength (Coil factor): 174 dBµA/m / 54 dB/m
Coil diameter: 232 mm
Mechanical dimensions: 0.20 m × 0.25 m × 0.39 m
Max. cubical shaped DuT: 11.3 × 11.3 × 11.3 cm
Terminals: 4 mm banana jacks and 7 mm screw terminals
Usable frequency range: DC – 300 kHz
Inductance (per coil): 2.83 mH
Inductance (pair of coils): 6.42 mH
Resistance (per coil): 1.42 Ω
Coil capacitance (pair of coils): 22 pF
Resonance frequency (pair of coils): > 400 kHz
Weight: 4.7 kg
