Measuring Range: 0.5 – 50.0 cN
Resolution: 0.1 cN
Measuring Head Width*: 43 mm
SCHMIDT Calibration Material**: PA: 0.12 mm Ø
Calibration: According to SCHMIDT factory procedure
Accuracy: ±1 % full scale ±1 digit or better; typical ±0.5 % full scale
Measuring Units: cN, g, N or lb, switchable
Overrange: Approx. 10 % full scale, without accuracy guarantee
Overload protection: 200 % full scale
Measuring principle: Strain gauge bridge
Measuring roller deflection: Max. 0.5 mm
Signal processing: Digital
Damping: Adjustable electronic damping, averaging
Sampling rate internal: Approx. 1 kHz
Sampling rate: 250 Hz (250 readings/sec)
Display: Colour-TFT 128 x 160
3 different displays: Numeric; Numeric with live bargraph; Numeric with graph (time-tension)
Display update rate: 2 times per second
Memory: Last, AVG, MIN, MAX, STD Dev
Auto power off: After 3 minutes of non-use
Temperature range: 10 – 45 ºC
Air humidity: 85 % RH, max.
Power supply: LiPo accumulator (approx. 25 h continuous use, charging time approx. 3.5 h), USB AC adapter 100 – 240 V AC with 4 adapters (EU/USA/UK/AUS-NZ)
Housing material: Plastic (POM)
Dimensions: See Dimensions
Weight, net (gross): Approx. 200 g (600 g)
Other units of measure are available, such as g.
* Width of filament guide
** Suitable for 95 % of applications – PA = Polyamide Monofilament
Delivery Includes: carrying case, USB AC adapter with 4 adapters (EU/USA/UK/AUS-NZ), charging cable, operating instruction in German or English (as requested), Certificate of Compliance with the order 2.1 according EN 10204 free of charge
