Nominal Load in N: 1000 N
Tension Range: 10 up to 2000 N – nominal load
Accuracy: 0.5 % nominal load
Max. applied force: 160 % of nominal load, overload protection afterwards
Overload: 10 times of nominal load, max. 3200 N (depending on measuring range)
Transverse force at the axle: Max. 100 % nominal load
Axle deflection: Approx. 0.5 mm
Measuring principle: Strain gauge bridge
Output signal: 5 – 20 N: 1 mV/V; From 50 N: 1.5 mV/V
Max. power supply: 10 V DC
Connecting cable: 5 m
Bridge resistor: 700 Ω
IP code: IP67 (IP 54 optional)
Temperature range: -10…+70° C
Housing: Stainless-steel
Weight, net (gross): Approx. 1100 g (1600 g) inclusive 5 m cable
Delivery Includes: Tension sensor SFZ with cable and transport packaging, operating instruction in German or English (as requested)
