Nominal Load: 50 N
Measuring range: 10 bis 500 N – nominal load
Accuracy: 0.5 % FS (full scale)
Max. applied force: 160 % of nominal load, overload protection afterwards
Overload: 10 times of nominal load, max. 2000 N (depending on measuring range)
Transverse force at the axle: Max. 100 % nominal load
Axle deflection: < 0.5 mm
Measuring principle: Strain gauge bridge
Output signal: 1 mV/V
Max. power supply: 10 V DC
Connecting cable: 5 m
Bridge resistor: 350 Ω
IP code: IP 54
Temperature range: -10…+70° C
Housing: Stainless-steel
Weight, net (gross): Approx. 400 g (700 g) inclusive 5 m cable
Delivery Includes: Tension sensor SFD with cable and transport packaging, operating instruction in German or English (as requested)
