Pulse voltage: 4.0 - 10.0 kV
Pulse shape: rise time 0.1 µs pulse width 2000 µs idle speed (> 20 MOhm)
Waveform under load: 50 Ohm open circuit voltage = 50 % U pulse width 2.773 µs
Polarity: positive, negative, alternating
Energy of the source: 1 Joule - at 7 kV charging voltage
Impedance of the source: 50 Ohm
Interface: RS 232
Loading time: < 5 seconds
HV output: earth-related
Number of pulses: 1 - 999
Repetition rate: 5 - 999 sec
Phase angle: φ = 0° - 359°, 1° steps, mains synchronous triggering
BNC socket for: voltage measurement; 1 V = 1 kV test voltage
BNC socket for: trigger pulse oscilloscope (TTL level)
Test sample connection: HV cable
Operating temperature: 0 - 40 °C
Dimensions: 19 Housing (3 RU)
Weight: 10 kg
Electronics input: 230 V / 50 Hz / 2.5 A
