LABSAT SatGen ຊອບແວ SatGen (SatGen v3 L1 band Single constellation)
Technical Specifications
Constellation all variants: GPS/Galileo/GLONASS/BeiDou/NavIC
Data format: IF, I, Q, I&Q
Quantisation: 1 bit, 2-bit, 3-bit
File format: .bin / .ls2 / .ls3 / .LS3W
File Size/ Duration: Unlimited/ 7 days
One hour scenario data size:
LabSat: 7 GB
LabSat 2 & RT: 14.4 GB
LabSat 3: 14.4 GB
LabSat 3 Wideband: 169 GB
Almanac file format: .alm / .agl / .xml
NMEA Input File Format: $GGA
Operating System: Win 7 64-bit, Win 8 64-bit, Win 10 64-bit
Minimum recommended PC requirements
SatGen v3 Single, Dual & Triple constellation:
Single constellation: Min 4GB RAM
Dual and Triple constellation: Min 8GBRAM
Real-Time:
Single constellation: up to 16 satellites.
4-core Intel i7 3.8 GHz Turbo frequency
Dual constellation: up to 28 satellites.
8-core Intel i7 Extreme 3.5GHz Turbo frequency
10-core Intel Xeon 2.8GHz Nominal frequency
SatGen v3 Wideband:
Minimum RAM specification: 16GB
4-core Intel i7 3.8 GHz Turbo frequency
