Directive No. 4 of
DCV: 400m/4/40/400/1000V - 0.1mV / + -0.5%
ACV: 4/40/400/1000V - 1mV / + -1.2%
DCA: 400u/4000u/40m/400m/10A - 0.001mA / + -1.4%
ACA: 400u/4000u/40m/400m/10A - 0.001mA / + -1.8%
Ω resistor: 400/4k/40k/400k/4M/40MΩ - 0.1Ω / + -1.2%
Capacitor F: 50n/500n/5u/50u/100uF - 0.01nF / + -5%
Frequency Hz: 5/50/500/5k/50k/Hz ~ 100kHz - + -0.3%
Check diode, continuous monitoring of circuit
Source: R6Px2
Features:
■3-3/4 digits 4000 count
■3-3/4 digits 4000 count
■Easy to read large LCD with Backlight
■Large breaking capacity fuse 30kA
■1.5V battery check function
■Thermo plastic elastomer, high resistance against drop shock
■Safety cap on current terminal
■Data hold, Range hold, Relative function
■Continuity check, Diode test
■Auto power off function (30min.)
■Maximum 20A can be measured if the measurement time is less than 10 seconds. (Take 10 minutes or longer intervals between measurements)
Display : numeral display 4000
Sampling rate : 3 times / sec.
AC frequency bandwidth : 40〜400Hz (sine wave)
Option:
Clamp probe : CL-20D, CL-22AD, CL33DC
HV probe : HV-60
Carrying case : C-77, C-77H
Clip adapter : CL-13a, CL-14,CL-15a, CL-DG3a, TL-9IC
Test lead : TL-21M, TLF-120
