INPUT
Nominal Voltage: 220VAC
Voltage Range: 120VAC ~ 275VAC
Phase: 1 Phase (2 wires + N)
Frequency: 50/60Hz (40Hz ~ 70Hz)
Power Factor: ≥ 0.99
OUTPUT
Power Capacity: 6KVA / 5,4KW
Voltage: 220V ± 1%
Phase: 1 Phase (2 wires + N)
Waveform: True sine wave
Frequency: 50/60Hz ± 0.2Hz (Battery mode)
Efficiency: 94% (98% ECO Mode)
Overload Capability: 105% ~125% in 1 min, 125%~150% in 30 sec , > 150% in 0.5 sec
BATTERY
Battery type: 12VDC, seal acid, maintain free
Back up time: > 4 mins
INTERFACE
Control panel: On/ Off button / Seft-test / Silent
Display: LCD (Load capacity, Battery capacity, Input, Output, Operating)
Communication port: RS232, Intelligent Slot
Extendable card: AS400 Card, USB Card, CMC Card, NMC Card
Software management: Winpower
Transfer time: 0 ms
Maintenance bypass switch: Option
Parallel: Upto 3 UPSs in parallel
EPO: Option
ENVIRONMENT
Operating Temperature: 0 to 40 degrees Celsius
Operating Humidity: 20% to 90% (condensation)
STANDARDS & SAFETY
Audible Noise: < 50 dB (not buzz)
Regulations: IEC 62040, IEC 61000
DIMENSIONS / WEIGHT
Dimensions W x D x H (mm): 248 x 500 x 565
Weight (Kg): 59
