- Power rating: 400KVA/400KW
- Input
+ Wiring: Three phase+Neutral+Ground
+ Input voltage range: 240 ~ 478Vac / 138 ~ 276Vac
+ Bypass voltage range: 340 ~ 438Vac / 196 ~ 253Vac
+ Frequency: 50/60Hz
+ Frequency range: 42 - 70Hz
+ Power factor: ≥ 0.99
+ THDI: <3% @ full linear load
- Output
+ Voltage : 230/400Vac（220/380，240/415 optional）
+ Freqency: 50Hz / 60Hz
+ Power factor: 1
+ THDV: <1% @ full linear load
+ Overload: 10mins@111–125% ，1min@126
+ Parallel: 4 units
- Efficiency
+ Double conversion mode: Up to 97%
+ ESS mode: Up to 99%
- Battery
+ Battery type: VRLA，NiCad，Lithium battery
+ Battery Voltage: 480V（40 pcs）~690V (50 pcs）， default 480V
+ Charge current （max）: 280A
- Environment
+ Ambient temperature: 0-40°C
+ Storage temperature: –15 ~ +55°C
+ Ambient humidity: 5 - 95 %
+ Altitude No derating: No derating < 1000m
- Physical
+ Diamension (W*D*H): 1100*1000*2000
+ Net Weight: 650kg
+ Gross weight: 770kg
- Quality (Safty): IEC/62040
