- Power rating: 20KVA/20KW
- Input
+ Wiring: Wiring Three phase+Neutral+Ground
+ Mains voltage range: 201 ~ 478Vac (L-L); 116 ~ 276Vac (L-N)
+ Bypass voltage range: 338 ~ 458Vac (L-L); 195 ~ 264Vac (L-N)
+ Frequency: 50/60Hz
+ Frequency range: 42 - 70Hz
+ Power factor: ≥ 0.99
+ THDi: <2% linear load; <5% non-linear load
- Output
+ Voltage : 230/400Vac default (220/380V,240/415V optional)
+ Votlage regulation: <1% @ steady state
+ Power factor 1
+ Overload:
102 ~ 110%, 60mins
111 ~ 125%, 10mins
126 ~ 150%, 1min
+ Parallel: Up to 4 units
- Efficiency
+ Online mode: Up to 96%
+ ECO mode: Up to 99%
- Battery
+ Battery Voltage: 320V~607V (432V default)
+ Max charge current: 25A
- Environment
+ Ambient temperature: 0-40°C
+ Storage temperature: –15 ~ +55°C
+ Ambient humidity: 5 - 95 %
+ Altitude No derating: < 1000m
- Physical
+ Dimension (W*D*H): Standard
+ Net Weight: 330*668*521mm
+ Gross weight: 50kg
- Quality (Safty): IEC/62040
