1. Provide database management service, can interface with BIM system, realize visualization of test result model; linkage with database, can perform detection result cloud AI (artificial intelligence) analysis
2. National Standard: GB/T 24967-2010
3. Signal processing and excitation technology: reduce excitation residual signal, ground reflection signal; integrated processing, average processing using automatic excitation technology
4. Operating system: windows
5. Number of channels: 2 channels (expandable to multiple channels with VMC technology), trigger channel and receiving channel are interchangeable
6. Waveform noise processing and spectrum analysis methods: mobile smoothing, BPF, EMD, FFT, MEM
7. Analysis of results: Automatically reject abnormal data and obtain optimal results by statistics
8. Data acquisition: support touch and wireless dual control mode; support single, continuous dual mode sampling
9. Platform: integrated platform
10. Working temperature: -10 ~ 40 ° C
11. Detection range: 0.7m ~ 5.0m
12. Test accuracy: the average measurement error is not more than +/- 4% or not more than +/- 8cm
13. Sampling frequency: 500KHz, adjustable
14. Sampling accuracy: floating point interpolation compensation to 24 bits
15. The maximum number of collection points: 20,000
16. Can display maximum / minimum voltage: 10V / 0.0001V
17. Effective resolution: 0.01m
18. Display: LCD display 1280*800
19. Location information: support GPS positioning
