Input Signals
Thermocouple: K, R, B, N, E, T, J, S, WRE5-26, WRE3-25
Thermal resistance: pt1000, pt100, cu50
Number of Channels: 8 – 256
Sampling: 1S or optional 0.1S
Isolation Voltage
Between power supply: 3000V DC
Between channels: 400V/AC/DC
Fault and Overvoltage Protection: Maximum withstand voltage ±15V
Input Resistance: > 2M (voltage type signal), < 50Ω (current type signal)
Temperature Drift: ± 25PPM/°C
Electrostatic Protection: 2000V
Communication Parameter: Baud rate 9600bps/115200bps, data bit 8, check bit N (none), stop bit 1
Power Supply: DC +8V to +28VDC (terminals), +5V (USB)
Power Protection: Power reverse protection, wrong connection protection
Power Consumption: 0.3W
Operation Environment: -30°C ~ +80°C, 0–100% RH (non-condensing)
Dimension: 117.6 × 76.5 × 25.7 mm
Protection Level: IP40 & Fire-proof level UL94
