SALUKI S3600-265 Vector Network Analyzer (300 kHz ~ 6.5 GHz, 2 ports)
Frequency Range: 300 kHz to 6.5 GHz
Frequency Resolution: 1 Hz
Frequency Accuracy: ±5×10-6 (23°C ± 3°C)
Number of Measurement Points: 2 to 20001
Measurement Bandwidth: 1 Hz to 2 MHz
Max. Dynamic Range
100kHz – 300kHz: 97dB, typ. 115dB
300kHz – 10MHz: 112dB, typ. 115dB
10MHz – 6GHz: 125dB, typ. 130dB
6GHz – 7GHz: 124dB, typ. 129dB
7GHz – 8.5GHz: 123dB, typ. 128dB
Output Power Range
100kHz – 300kHz: – 50dBm to +5dBm
300kHz – 7GHz: – 50dBm to +10dBm
7GHz – 8.5GHz: – 50dBm to +8dBm
Effective Directivity: 38dB – 49dB
Transmission Measurement Accuracy
+5dB to +10dB: 0.2dB / 2º
-50dB to +5dB: 0.1dB / 1º
-70dB to -50dB: 0.5dB / 3º
-90dB to -70dB: 2.5dB / 8º
Reflection Measurement Accuracy
-15dB to 0dB: 0.4dB / 3º
-25dB to -15dB: 1.0dB / 6º
-35dB to -25dB: 3.0dB / 20º
Trace Noise: 2 mdB rms (IFBW= 3 kHz)
Temperature Stability: 0.01 dB/℃
Measurement Time Per Point: 42 us
Typical Cycle Times Versus Number of Measurement Points: 51ms, 201ms, 401ms, 601ms (IFBW 30kHz)
Uncorrected
51 points: 13ms
201 points: 52ms
401 points: 104ms
1601 points: 413ms
Full 2-Port Calibration
51 points: 34ms
201 points: 73ms
401 points: 125ms
1601 points: 434ms
Measurement Parameters: S11, S21, S12, S22
Test Port Connector: N-type, female
Number of Built-In Ports: 2 ports
Impedance: 50 Ω
Power Consumption: 65 W
Dimension: 425 (W) × 400 (H) × 122 (D) mm
Weight: 7.5 kg
