Rosenberger 08S141-270L5 ປຸ່ມຕໍ່ສາຍສົດຕົວ

Gender: Plug (Pin)

Polarity: Standard

Frequency: 70 GHz

Impedance: 50 Ohms

RF Series: 1.85 mm

Body Style: Straight

Cable Type: RTK 047, UT 047

Body Finish: Gold

Orientation: Straight

Body Material: Brass

Mating Cycles: 500 Cycle

Mounting Style: Cable Mount / Free Hanging

Voltage Rating: 150 V

Contact Plating: Gold

Contact Material: Copper Alloy

Maximum Frequency: 70 GHz

Termination Style: Solder

Coupling Mechanism: Threaded

Contact Termination: Solder

Insulation Resistance: 5 GOhms

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
