Width: 1.8 mm
Height: 0.95 mm
Length: 3 mm
Fall Time: 60 ns
Rise Time: 40 ns
Technology: Si
Unit Weight: 12 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 16 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 11 ns
Typical Turn-Off Delay Time: 160 ns
Id - Continuous Drain Current: 3 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 3.5 S
Rds On - Drain-Source Resistance: 62 mOhms
Vds - Drain-Source Breakdown Voltage: 12 V
Vgs th - Gate-Source Threshold Voltage: 1 V
