ROHM Semiconductor BU16501KS2-E2 ເດີເວີ LED LED DRIVER3-WIRE SERIAL INTER

Features: LED Matrix drive, Interface

Topology: PWM

Input Voltage: 2.7 V to 5.5 V

Mounting Style: SMD/SMT

Output Current: 20 mA, 42.5 mA

Number of Outputs: 16 Output

Moisture Sensitive: Yes

Number of Channels: 24 Channel

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.7 V

Operating Frequency: 1.2 MHz

Supply Current - Max: 2.1 mA

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.7 V

Pd - Power Dissipation: 1.3 W

Low Level Output Current: 3 mA

Operating Supply Voltage: 2.7 V to 5.5 V

High Level Output Current: - 2 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
