RIGOL DP932E ການສະຫນອງພະລັງງານ DC Linear ທີ່ສາມາດວາງແຜນໄດ້ (3CH; 198W)
Number of Channels: 3
Total power: 198W
DC Output (0℃~40℃):
+ Voltage/Current :
CH1, CH2: 0 to 32 V/0 to 3 A
CH3: 0 to 6 V/0 to 3 A
+ OVP/OCP
CH1, CH2: 1 mV to 35.2 V/1 mA to 3.3 A
CH3: 1 mV to 6.6 V/1 mA to 3.3 A
Load Regulation Rate:
+ Voltage[2]: <0.01%+2 mV
+ Current: <0.01%+250 μA
Line Regulation Rate:
+ Voltage: <0.01%+2 mV
+ Current: <0.01%+250 μA
Output ripple and noise (20 Hz to 20 MHz):
+ Normal mode voltage: <350 μVrms/2 mVpp
+ Normal mode current: <2 mArms
Accuracy 12 months (25ºC±5ºC):
+ Programming
CH1, CH2: Voltage: 0.05%+10 mV; Current: 0.2%+5 mA
CH3: Voltage: 0.1%+5 mV; Current: 0.2%+5 mA
+ Readback:
CH1, CH2: Voltage: 0.05%+10 mV; Current: 0.15%+5 mA
CH3: Voltage: 0.1%+5 mV; Current: 0.15%+5 mA
Resolution( Standard):
+ Programming: Voltage: 10 mV; Current: 1 mA
+ Readback: Voltage: 10 mV; Current: 1 mA
+ Display: Voltage: 10 mV; Current: 1 mA
Command processing time: <10 ms
OVP/OCP Accuracy:
+ OVP accuracy, ± (% of output + offset): 0.2%+20 mV
+ OCP accuracy, ± (% of output + offset): 0.5%+20 mA
Mechanical characteristics:
+ Dimension: 239 mm (W) x 157 mm (H) x 419 mm (D)
+ Weight: 9.15 kg
+ Rack mount kit: Three rack-units (3U), 1/2-rack form factor
