RIGOL DHO812 Oscilloscope ດິຈິຕອນ (100 MHz, 1.25 GSa/s, 25 Mpts, 2CH)
Analog Bandwidth (-3 dB): 100 MHz
Rise Time (10% to 90%, typical): ≤3.5 ns
No. of Analog Channels: 2 + EXT
Sampling Mode: Real-time Sampling
Max. Sample Rate of Analog Channel: 1.25 GSa/s (single-channel), 625 MSa/s (full-channel)
Max. Memory Depth: 25 Mpts (single-channel), 12.5 Mpts (full-channel)
Max. Waveform Capture Rate: 30,000 wfms/s (Vector Mode)/ 1,000,000 wfms/s (UltraAcquire Mode)
Vertical Resolution: 12 bits
Hardware Real-time Waveform Recording and Playing: Max. 500,000 frames
Peak Detection: Capture 2 ns glitches
LCD Size and Type: 7" capacitive multi-touch screen
Display Resolution: 1024x600
Power Supply Interface: Type-C
Power Voltage: DC 12V, 3A
Power: Max. 36 W (when connected to various interfaces, USB storage device, active probes)
Temperature Range:
Operating: 0°C to 50°C
Non-operating: -30°C to +60°C
Humidity Range Operating
below +30°C: ≤90% RH (without condensation)
+30°C to +40°C, ≤75% RH (without condensation)
+40°C to +50°C, ≤45% RH (without condensation)
Humidity Range Non-operating
below: 60°C: ≤90% RH (without condensation)
Altitude
Operating Below 3,000 m
Non-operating Below 15,000 m
Dimensions: 265.35 mm (W) x 161.75 mm (H) x 77.38 mm (D)
Non-volatile Memory
Internal Capacity: 8 GB
Reference Waveform: Displays 10 internal waveforms
Setting: Storage is limited by the capacity
USB Capacity: Supports the USB storage device that conforms to the industry standard
