Specifications
Analog Bandwidth (-3 dB) : 70 MHz
Input Channels: 2+EXT
Rise Time (10% to 90%,Typical): ≤5 ns
Sampling Mode: Real-time sampling
Max. Sample Rate of Analog Channels:
+ 2-channel model: 2 GSa/s (single channel[1]), 1 GSa/s (all channels[3])
+ 4-channel model: 2 GSa/s (single channel[1]), 1 GSa/s (half channels[2]), 500 MSa/s (all channels[3])
Standard Memory Depth
+ 2-channel model: 50 Mpts (single channel[1]), 25 Mpts (all channels[3])
+ 4-channel model: 50 Mpts (single channel[1]), 25 Mpts (half channels[2]), 12.5 Mpts (all channels[3])
Optional Memory Depth
+ 2-channel model: 100 Mpts (single channel[1]), 50 Mpts (all channels[3])
+ 4-channel model: 100 Mpts (single channel[1]), 50 Mpts (half channels[2]), 25 Mpts (all channels[3])
Max. Waveform Capture Rate
+ 50,000 wfms/s (Vector Mode)
+ 1,500,000 wfms/s (UltraAcquire Mode)
Vertical Resolution: 12 bits
Hardware Realtime Waveform Recording and Playing: Up to 500,000 frames
Peak Detect: Capture glitches as narrow as 2 ns
Display Size and Type: 10.1-inch capacitive multi-touch display
Display Resolution: 1280 × 800
Power
Power Voltage: AC 100 to 240 V, 50 to 60 Hz
Power: 400 VA maximum (connect various interfaces, USB storage device, and active
probes)
Fuse: 3.15 A, T degree, 250 V
Environment
Temperature Range: Operating: 0℃ to +50℃; Non-operating: -30℃ to +60℃
Humidity Range:
+ Operating:
below +30℃, ≤90% RH (without condensation)
+30℃ to +40℃, ≤75% RH (without condensation)
+40℃ to +50℃, ≤45% RH (without condensation)
+ Non-operating below 60℃: ≤90% RH (without condensation)
Altitude:
+ Operating Below 3,000 m
+ Non-operating Below 15,000
Mechanical Characteristics
Dimensions: 358.14 mm (W) x 214.72 mm (H) x 120.62 mm (D)
Rack Mount Kit: 4U
Weight[6] Net: 3.8 kg; Shipping: 5.37 kg
Non-volatile Memory
Data/File Storage:
+ Setup/Image: setup (*.stp), image (*.png, *.bmp, *.jpg)
+ Waveform Data: CSV waveform data (*.csv), binary waveform data (*.bin,), list data (*.csv), and reference waveform data (*.ref, *.csv, *.bin)
Internal Capacity: 8 GB
Reference Waveform: Displays 10 internal waveforms
Setting: Limited by size of USB drive
USB Capacity: Industry standard flash drives
