Channel 1
Max. Frequency 25 MHz
Sample Rate 125 MSa/s
Basic Waveforms Sine, Square, Ramp, Pulse, Noise, DC, Dual-tone
Advanced Waveforms PRBS, RS232, Sequence
Built-in Arbitrary Waveforms 160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine,
Lorentz, etc.
Sine 1 μHz to 25 MHz
Square 1 μHz to 10 MHz
Modulation Characteristics
Modulation Type AM, FM, PM, ASK, FSK, PSK, PWM
AM
Carrier Waveform Sine, Square, Ramp, Arb
Source Internal/External
Modulating Waveform Sine, Square, Ramp, Noise, Arb
Modulation Depth 0% to 120%
Modulation Frequency 2 mHz to 1 MHz
FM
Carrier Waveform Sine, Square, Ramp, Arb
Source Internal/External
Sweep Characteristics
Carrier Waveform Sine, Square, Ramp, Arb
Type Linear, Log, and Step
Orientation Up/Down
Start/Stop Frequency Same as the upper/lower limit of the corresponding carrier frequency
Sweep Time 1 ms to 500 s
Hold/Return Time 0 ms to 500 s
Source Internal, External, Manual
Marker Falling edge of the sync signal (programmable)
Measurement Function Frequency, Period, Positive/Negative Pulse Width, Duty Cycle
Frequency Resolution 7 digits/s (Gate Time = 1 s)
Frequency Range 1 μHz to 240 MHz
Period Measurement Measurement Range
Power Supply
Power Voltage 100 V to 127 V (45 Hz to 440 Hz)
100 V to 240 V (45 Hz to 65Hz)
Power Consumption Lower than 30 W
Display
Type 4.3-inch TFT LCD touch screen
Resolution 480 horizontal × RGB × 272 vertical resolution
Color 16 M
Environment
Temperature Range Operating: 0℃ to 45℃
Non-operating: -40℃ to 60℃
Cooling Method Natural air cooling
Humidity Range
Below 30℃: ≤95%RH
30℃ to 40℃: ≤75%RH
40℃ to 50℃: ≤45%RH
Altitude Operating: below 3,000 meters
Non-operating: below 15,000 meters
Mechanical Characteristics
Dimensions (W×H×D) 237.4 mm × 97 mm × 268 mm
Weight Package excluded: 1.75 kg
Package included: 2.85 kg
Interface USB Host, USB Device, and USB-GPIB
IP Protection IP2X
Calibration Interval 1 year (recommended)
