Renesas Electronics R5F565N4BGFB#30 MCUs 32BIT MCU RX65N 512K/256K QFP144

Core: RXv2

Width: 20 mm

Height: 1.4 mm

Length: 20 mm

Data RAM Size: 256 kB

Data RAM Type: SRAM

ADC Resolution: 12 bit

DAC Resolution: 12 bit

Data Bus Width: 32 bit

Interface Type: CAN, I2C, SCI, USB

Mounting Style: SMD/SMT

Number of I/Os: 111 I/O

Watchdog Timers: Watchdog Timer

Processor Series: RX65N

Moisture Sensitive: Yes

Program Memory Size: 512 kB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 2.7 V

Number of ADC Channels: 29 Channel

Maximum Clock Frequency: 120 MHz

Number of Timers/Counters: 2 x 8 bit, 12 x 16 bit, 2 x 32 bit

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
