Scan interface: 8 road
Pressure test
The output voltage
AC: 0.05kV-5.00kV ±2%
DC: 0.05kV-6.00kV ±2%
Current test range
AC: 0 — 20mA ±(2% of reading + 5 digits)
DC: 0 — 10mA ±(2% of reading + 5 digits)
fast discharge: Automatic discharge after test (DCW)
Arc Detection
Measuring range AC/DC: 1mA-20mA
General parameters
Voltage rise time: 0.1S～999.9S
Test time setting: 0.2S～999.9S
Voltage fall time: 0.1S～999.9S
Waiting time (IR): 0.2S～999.9S
time precision: ±(1%+0.1S)
interface: Handler, RS232, RS485, USB DEVICE, USB HOST
Working temperature and humidity: 10℃～40℃,≤90%RH
Power Requirements: 90～121V AC (60Hz) or 198～242V AC (50Hz)
Power consumption: <400VA
Standard: RK00001 power cord, wire interface transfer driver CD, RS232 communication cable RK00002, RS232 to USB cable RK00003, USB to square port cable, RK8N+ high voltage rod, connecting cable RK00006, 16G U disk (instruction manual), RK26003A tester, RK26003B test line
Optional: RK00031 USB to RS485 female serial cable industrial-grade cable length 1.5 meters host computer
Weight (net weight): 19.75KG
Dimensions (H×D×L): 174mm×450mm×352mm
