input power: 50/60Hz±5% 115/230VAC±10%
Output current: 3-30Aac constant current source, resolution: 0.1A/step, accuracy: ± (2% set value + 0.02A)
The output voltage: 6Vac MAX (measured with open circuit)
Output frequency:50Hz/60Hz optional
Resistance range: 0-120mΩ(>10A)/1-510mΩ(10A), resolution: 1mΩ/step, accuracy: ±(2% reading value + 1 word)
Zero adjustment: MAX 100mΩ, resolution: 1mΩ/step, accuracy: ± (2% reading value + 1 word)
upper limit setting: Range: 0-510mΩ, Resolution: 1mΩ/step, Accuracy: ±(2% set value + 1 word)
testing time: Range: 0.5-999.9 seconds (0=continuous test)
control interface
Input: test (TEST), reset (RESET), withstand voltage test (WITHSTAND)
PROCESSING). Output: Test passed (PASS), Test failed (FAIL), Test in progress (TEST-IN-PROCESS)
Test result output method:Buzzer, LCD display numbers, control interface status output
memory group: sets of test condition memory
Correction method: software correction
monitor: 16×2 LCD display with backlight
temperature humidity: 0℃～40℃，≤75%RH
Dimensions (D×W×H): 410mm×290mm×100mm
Standard accessories: RK00001 power cord, RK00005 test cord, RK00002 cable
security lock With keyboard lock function
weight: 8.7KG
fuse: 3.15A
