Test resistance range: 1uΩ-200MΩ
Test accuracy: 0.05%+2 words (slow) 0.05%+5 words (medium speed) 0.5%+5 words (fast)
Basic measurement accuracy:
20mΩ 0.1%+3 characters,
200mΩ-200kΩ 0.05%+2 characters
2MΩ0.1%±2 characters
20MΩ-200MΩ 0.1%±5 characters
Test current: 1A 100mA 10mA 1mA 100uA 10uA
Test range: 20mΩ 200mΩ 2Ω 20Ω 200Ω 2kΩ 20kΩ200kΩ 2MΩ 20MΩ
Resolution: 1uΩ 10uΩ 100uΩ 1mΩ 10mΩ100mΩ 1Ω 10Ω 100Ω 1000Ω
rate: Slow 3 times/sec Medium 18 times/sec Fast 60 times/sec
Range method: automatic / manual
Screen: TFT-LCD 5 inch resistive touch LCD screen
temperature measurement: With temperature measurement compensation
number of readings: 51/2Bit display, maximum 20000
language: Chinese-English
calibration: Short circuit full scale clear
document: Parameters are automatically saved
beep: close, pass, fail
trigger Internal, External, Manual, Remote
interface: HANDLER interface, RS232 interface, RS485 interface, USB interface, temperature compensation interface
Programming language: SCPI
test end: Four terminal test
Comparator sorting: 10-speed comparator
Visual display of upper and lower limit values software settings
Working temperature and humidity: 0℃-40℃,≦75%RH
power supply: 100V-121V, 198V-242V, 47.5-63Hz
Fuse Specifications: 1A 250V 2A 110V slow blow
Power consumption: ≦20VA
Outline volume (D×H×W: 360mm×105mm×235mm
Shelf volume (D×H×W): 351mm×108mm×260mm
weight: About 5KG
Optional accessories: RK00031 USB to RS485 female serial cable industrial grade cable 1.5 meters long
Random standard accessories: Power cord RK00001, four-terminal test cable RK00033, temperature probe RK00034, RS232 communication cable RK00002, RS232 to USB cable RK00003, USB to square port connection cable RK00006, 16G U disk (host computer and manual), wire interface transfer driver CD, SCSI 57 series 36P male
