Performance Indicators
Detector Type: Uncooled VOx infrared detector
Resolution: 1024×768
Detector Frame Rate: 30Hz
Pixel Pitch: 12μm
Spectral Band: 8~14μm
NETD: ≤50mK at 25℃,F#1.0
Image Adjustment
Palette: Support (20 types)
Digital Zoom: 1.0~4.0× continuous zoom (step size: 0.1)
Brightness/Contrast Adjustment: Manual/Auto 0/Auto 1
Image Processing: Non-uniformity correction/digital filter noise reduction/digital detail enhancement
Mirroring: Horizontal/Vertical/Diagonal
Network Function
Network Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, IGMP, SMTP, NTP, QoS and other network protocols.
Platform Access: ONVIF, GB28181, SDK
Simultaneous Previewed Videos: Up to 20 channels
User Management: Up to 20 users, 3 levels: administrator, operator and user
Browser: Support IE8+ and various languages
Lens
Lens Type: Athermalized/Motorized fixed-focus /Continuous zoom
Focus Mode: Manual/Automatic
Electric Focusing: Support
Electric Zooming: Support
Digital
Power Supply Range: 5-24V DC (Recommended voltage of 12V DC)
Typical Power Consumption at 25°C: ＜2.4W
Digital Video: LVCMOS/LVDS/BT.1120/SDI
Communication Interface: RS-232/RS-485
Weight: 102.7g (without lens)
Size: 45mm×45mm
Network Type
Power Supply Range: 9-15V DC (Recommended voltage of 12V DC)
Typical Power Consumption at 25°C: ＜3.0W
Communication Interface: One RJ45 10M/100M adaptive Ethernet port, one RS-485
Alarm Interface: One alarm input, one alarm output
Audio Interface: One audio input, one audio output
Weight: 180.9g (without lens)
Size: 45mm×45mm
Environment Adaptability
Operating Temperature: -40℃～+60℃
Storage Temperature: -45℃～+85℃
Humidity: 5 ~ 95%, non-condensing
