Performance Indicators
Detector Type: HgCdTe cooled infrared detector
Resolution: 640×512
Frame Rate: 100Hz/50Hz/30Hz
F#: 4.0/F5.5
Pixel Pitch: 15μm
Spectral Band: 3.7±0.2μm～4.8±0.2μm
NETD: ≤15mK@25℃
Detector Defective Pixel Rate: ≤0.5%
Cooling Time@25°C: ≤7min
Image Adjustment
Brightness/Contrast Adjustment: Manual/Auto
Polarity: Black-hot/White-hot (white-hot by default)
Reticle: Display/Blank/Move
Image Processing: Non-uniformity correction, digital filter noise reduction, digital detail enhancement
Mirroring: Horizontal/Vertical/Diagonal
Interface
Analog Video: PAL
Digital Video: Cameralink/SDI
Serial Communication Interface: RS422(default baud rate: 115200)
Physical Characteristics
Dimensions (Without lens): ≤ 480g (without isolation)
Weight (Without lens): 120×88×57mm (±1) (without isolation)
Environment Adaptability
Operating Temperature: -40℃～+60℃
Storage Temperature: -45℃～+65℃
Temperature Shock: -45℃~+65℃（≤5℃/min）
Random Vibration: 4.2g
Shock: Final peak sawtooth wave, 40g, 11ms (18 times in three axes and six directions in total)
MTTF: ≥8000h
Power and Interface
Typical Power Consumption at 25°C: Stable power consumption ≤ 10W, peak power consumption ≤ 25W
