Rational CMS-6105M ລະບົບການວັດແທກການປະສານງານຄູ່ມື (X: 600 Y: 1000 Z: 500mm)
Travel (mm)
X: 600
Y: 1000
Z: 500
Accuracy:
Space accuracy: MPEE=(3.5+L/250)μm
Monaxial accuracy: MPEE1=(3.0+L/250)μm
Differentiate force：0.5μm
Construction: Sliding bridge
Total power: 50W(excluding PC)
System characteristics:
Probing system: NENISHAW WH20i/ Video probing system
Measuring software：RationalDMIS(manual)/ QMS3D-M
Dimension (m): 1.14×1.5×2.4
Weight: 1180kg
Max. load-bearing: 500kg
Packing dimension (m): 1.35×1.95×2.4
Power supply：AC 100-240V 50/60Hz
Temperature range: 20±2℃ <1℃/h <℃/24h <1℃/m
Air flow：120L/min（0.4MPa）
Bleed pressure: 0.5MPa. Humidity: 40%—70%
Product brief:
Manual Coordinate Measuring Machine is a high precision instrument integrating optics, machinery, electronics and computing. It is convenient to measure coordinate point, profile and Dimension, and form and location tolerance.
It is mainly used in the field of machinery, electronics, instrument, meter, watch, light industry, plastics as well as measuring chambers, laboratories of institutes and universities, research institutes, metrological verification departments and workshops, etc.
