Primary Application: Production, Display Testing, Pixel-level Measurement, Advanced Vision
Sensor Pixel Resolution: 5312 x 3032
Sensor Megapixels: 16.1
Sensor Type: CMOS
System Dynamic Range (single exposure, per pixel): 70 dB (1 x 1 binning)
Luminance (Minimum)*: 0.0005 cd/m² Limit of Detection/ 0.0010 cd/m² @ SNR = 60/ 0.0015 cd/m² @ SNR = 100
Luminance (Maximum): 10¹⁰ cd/m² with optional ND filters
System Accuracy**: Illuminance ± 3%; Luminance (Y) ± 3%
Short-term Repeatability: Illuminance ± 0.03%; Luminance (Y) ± 0.03%
Lens Type: Electronically controlled focus and aperture
Focal Distances Available: 35, 50, 100 mm
Field of View (Full Angle, H x V degrees): 35 mm 24° x 14°; 50 mm 17° x 10°; 100 mm macro 8° x 5°
Minimum Measurement Time***: 0.5 sec
Spatial Measurement Capabilities: Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity
Units: foot-lambert, cd/m2, nit, W/sr/m2, foot-candles, lux, lux-s, W/m2, W-s/m2, candela, W/sr
Communication Interface: Ethernet 1000
Power: External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts
Dimensions (H x W x D): 86 mm x 86 mm x 170 mm
Weight: 1.1 kg
Operating Temperature: 5-35° C
Operating Humidity: 20 - 70% non-condensing
