Application:
Ideal for calibrating thermocouples, RTD, indicators, controllers,
transmitters, receivers and mA, mV, V, ohms measuring instruments
Current Terminal Input
Protection : Fuse: 100mA / 250V
Memory Function : 9 set of values for each parameter in generation
Backlight : LED Backlight
Power Supply : 230 VAC, 50 Hz
Loop Power Supply : 24V ±10%
Operating Temperature : 10 to 50°C
Instrument Casing : ABS Plastic
Instrument Dimensions : 300 mm x 260 mm x 120 mm (LxWxD)
Instrument Weight : 2 kg
Standard Delivery
1. Instrument : 1 no.
2. Carrying Pouch : 1 no.
3. Test Lead (2 wire) : 2 nos.
4. Test Lead (3 wire) : 1 no.
5. User Manual : 1 no.
6. Traceable Calibration Certificate
Optional:
Accredited (NABL) Calibration Certificate as per ISO/IEC 17025:2005 Standard
