Inspected PCB : Pre/Post SMT reflow oven inspection
Optical imaging system:
Camera : 12MP high-speed camera
Light source : Multi-angle high white light
Optical resolution : 10 μm/15 μm
Inspection speed : 400 ms/FOV
Programming mode : Manual programming, CAD data import, AI programming
Defect inspection:
Component defect : Deviation, missing parts, skew, inverted, overturned, wrong parts, damage, polarity
Soldering joint defect : Icicle, hole, solder bead, solder pad with less/more solder, bridging, warped foot, gold finger pollution/scratch
X-Y axis control system : Linear motor drive
X-Y axis control accuracy : 0.5 μm
PCB carrier size : 50×50mm(Min)～ 510×500mm(Max)
PCB curvature : ＜ 5mm or 2% of PCB diagonal length
PCB measurable thickness : 0.6-5 mm
PCB conveyor height : 880-920 mm
PCB flow direction : Left in and right out, right in and left out (factory setting)
Conveyor loading weight : 15kg
Conveyor width adjustment/conveying : Automatic width adjustment, belt conveying
Height limit of passable component:
Top : 45mm
Bottom : 45mm
Side : 3 mm
Weight : About 750 kg
Machine sizes : 1000*1500*1650mm
Power requirements : 200-240 V, single phase， 50/60 Hz， 3 kVA
Air source : 5-6 bar
Machine safety : Meet CE standards
Software : Offline programming software, maintenance station & SPC management system (optional) ,Barcode system (optional)
