Gain: 4 dBi, 5 dBi, 2.5 dBi
VSWR: 4
Style: Dome
Width: 46.5 mm
Length: 91 mm
Diameter: 54 mm
IP Rating: IP66
Impedance: 50 Ohms
Cable Type: 3 M RG174 x 3
Application: Cellular Radio, Wireless Applications
Cable Length: 3 m
Polarization: Linear, RHCP
Mounting Style: Direct / Permanent Mount
Electrical Type: Active
Number of Bands: 4 Band
Center Frequency: 750 MHz, 800 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2200 MHz, 2450 MHz, 2500 MHz, 1575 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, UHF
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, GLONASS, GNSS, GPS
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
