Pulse Electronics ANTX100P001B50003 ແນວຮັບສະສົມສະຕິກ 5GHz 2.5dBi 18.4x7.5mm 100mm

Gain: 2.5 dB

Style: I-Bar Flex

Width: 7.5 mm

Height: 45 mm

Length: 18.4 mm

Impedance: 50 Ohms

Cable Type: 100 mm RF1.13

Cable Length: 100 mm

Polarization: Linear

Power Rating: 1 W

Mounting Style: Adhesive Mount

Number of Bands: 1 Band

Center Frequency: 5.5 GHz

Mechanical Style: PCB Trace

Maximum Frequency: 5.875 GHz

Minimum Frequency: 5.15 GHz

Termination Style: Connector

Protocol - Sub GHz: IoT, ISM

Antenna Connector Type: IPEX MHF

Protocol - WiFi - 802.11: WiFi

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE

Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
