DC voltage (DCV)
Range: 200 mV, 2 V, 20 V, 200 V, 1000 V
Accuracy:
± (0.05% rdg+ 1 dig.) 200 mV~200 V range
± (0.1% rdg + 5 dig.) 1000 V range
Input impedance: 10 MΩ
AC voltage (ACV)
Range: 200 mV, 2 V, 20 V, 200 V, 750 V
Accuracy:
200 mV range: 50Hz ~ 50kHz ± (0.8%rdg+ 80digits)
2V ~ 20V range: 50Hz ~ 20kHz ± (0.8%rdg+ 80digits)
200 V range: 50Hz ~ 5kHz ± (0.8%rdg+ 80digits)
750 V range: 50Hz ~ 400Hz ± (1.0%rdg+50digits)
Input impedance: 2 MΩ
DC current (DCA)
Range: 20 mA, 200 mA, 2 A, 20 A
Accuracy:
± (0.35%rdg+10digits) 20 mA, 200 mA range
± (1.2%rdg+20digits) 2 A, 20 A range
AC current (ACA)
Range: 200 mA, 2 A, 20 A
Accuracy
200 mA range: 50 Hz ~ 5 kHz: ± (0.8%rdg + 80 digits)
2 A~20 A range: 50 Hz ~ 400 Hz: ± (1.0%rdg + 50 digits)
Resistance (Ω)
Range: 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ, 20 MΩ
Accuracy:
± (0.1%rdg+10 digits) 200 Ω range
± (0.1%rdg+5 digits) 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ range
± (0.6% rdg+5 digits) 20 MΩ range
Capacitance (F)
Range: 20 nF, 2 μF, 200 μF
Accuracy:
± (3.5% rdg+20 digits) 20 nF, 2 μF range
± (5.0% rdg+30 digits) 200 μF range
Frequency (Hz)
Range: 20 kHz, 200 kHz
Accuracy: ± (1.0% rdg + 20 digits)
hFE (PNP or NPN)
Display: 0 ~ 1000.0
Test condition: Current is approx.10 μA, Vce is approx.3 V
Power supply: CC 220 V / 110V, 50 / 60 Hz
Dimensions: 220 (W.) × 82 (H.) x 260 (D.) mm Aprox.
Weight: Approx. 2 kg
