Inputs
Input Channels: 1
Video: Composite (CVBS) 1 Vpp
Video System: PAL / NTSC / SECAM
Audio: 0.5 - 2 Vpp
Audio System: 2 x Mono / Stereo
Compression
Video: MPEG-2 MP@ML
Video Resolution: 720x576, 25 fps (PAL), 720x480, 30 fps (NTSC)
Audio: From 96 to 384 kbit/s. MPEG-1 Layer II Stereo, Mono, Dual, Joint Stereo
Insertion of DVB Tables: SDT, NIT, EIT
LCN Programming: Yes
Modulation
Standard: DVB-T (ETSI EN 300 744)
Constellation: QPSK, 16QAM, 64QAM
Bandwidth: 6 MHz, 7 MHz, 8 MHz
Guard interval: 1/4, 1/8, 1/16, 1/32
Code Rate: 1/2, 2/3, 3/4, 5/6, 7/8
Carriers: 2K, 8K
Frequency margin: From 50 to 865 MHz (channels 02 to C69)
MER > 38 dB
Output level: 80 dBµV
Attenuation: Up to 40 dB
Connections
Video: RCA female 75 Ω
Audio: RCA female
RF: 2 x F female (loopthrough) 75 Ω
Power supply: External Power supply 220 V / 12 V
Dimensions: 130 mm (W.) x 145 mm (H.) x 40 mm (D.)
