No of Channels: 16 Logic Channels
State Speed: 100MHz (Synchronous Capture)
Timing Speed: 1GS/s (Asynchronous Capture)
Number of state clocksupport: Two, Flexibility to sample on rising or fallingedge
Record Length: Smart Continuous streaming of data to HDD/SSDofhost computer
Voltage Level Support: 0 to 5V with Flexibility to define the logic threshold
Waveform Plot: Plots waveforms with flexible configurable bus diagram
Listing View: List all the data samples at each sampling point
Trigger for LA: Pattern Trigger, Pulse width trigger, Delay trigger
Protocol Decode Support: I2C, SPI, UART, I3C, SPMI, RFFE, CAN, andCANFD
Simultaneous Protocol Decoding: Yes, Users can analyze multiple protocols simultaneously. E.g.,Users can analyze I2C, SPI, and UART bus simultaneouslyandcapture the bus data and displays it in a time-correlatedviewwiththe corresponding time waveforms.
Protocol View with timingview (PA+LA): Displays the protocol-decoded data with a highsamplerateandtiming waveform at the same time
API Support: Support for Automation of Operation using Python
Connector type: Flying Lead Probe with Female Connectors
#16 Micro Grabber Test Clips as Optional Accessories
External Triggers: Trigger Out SMA Connector
Markers: Six, with delta information between twomarkers
Capture duration: Smart streaming of Protocol Data to host HDD/SSDReport: Report Generation in PDF and CSVformat
Host Connectivity: USB 3.0 Type-C
Dimensions: 115mmx90mmx25mm
Weight: 300g
Includes
5050 LA-EMBD Probe Cable: 1
5052 LA-EMBD CAN Probe Cable: 1
5060 Minicooper clamp test hookup (Pair): 4
3230 C-Type USB Cable: 1
3250 5V DC Power Adapter: 1
PGY-LA-EMBD-SW PGY-LA-EMBD 16 Channel Logic Analyzer Software in USB Stick
