Power: 20KW
Current: 0 ~ 80A; 0 ~ 800A
Voltage: 0 ~ 1200V
Min. Operating Voltage: 15V at 800A
Protections: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp Protection (OTP)
Constant Current Mode Range: 80A; 800A
Constant Resistance Mode Range: 9KΩ~1.5Ω; 1.5Ω~0.0187Ω
Constant Voltage Mode Range: 1200V
Constant Power Mode Range: 2000W; 20000W
Constant Voltage Mode + Constant Current Mode Range: 1200V; 800A
Constant Voltage Mode + Constant Power Mode Range: 1200V; 20000W
Surge & Normal current: 0~800A
Dynamic Mode:
- Timing: 0.010~9.999 / 99.99 / 999.9 / 9999mS
- Current: 0~80A; 80~800A
Measurement
- Voltage Read Back Range (5 Digital): 0~120V; 120~1200V
- Current Read Back Range (5 Digital): 0~80A; 80~800A
- Power Read Back Range: 20000W
Typical Short Resistance: 0.0188Ω
Maximum Short Current: 800A
Load ON Voltage: 0.96 ~ 240V
Load OFF Voltage: 0 ~ 240V
Power Consumption: 1450VA
Dimension (HxWxD): 887x444x763mm
Weight: 140.5 kg
Temperature: 0~40℃
