Power: 0~4000W / 0~6000W max
Current: 0~160A / 0~240A max
Voltage: 0~1200V
Min.Operatting Voltage: 15V @ 160A
Protections
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 104%
Over Voltage Protection (OVP): 105%
Over Temp Protection (OTP): 90℃ ± 5℃
Constant Current Mode
Range: 0~16A / 0~160A
Resolution: 0.000256A / 0.00256A
Accuracy: ± 0.05% of (Setting + Range)
Constant Resistance Mode
Range: 7.5~450000Ω / 0.09375~7.5Ω
Resolution: 0.0000022S / 0.000125Ω
Accuracy: ± 0.2% of (Setting + Range)
Constant Voltage Mode
Range: 0~120V / 0~1200V
Resolution: 0.002V / 0.02V
Accuracy: ± 0.05% of (Setting + Range)
Constant Power Mode
Range: 0~400W / 0~4000W
Resolution: 0.0064W / 0.064W
Accuracy: ± 0.1% of (Setting + Range)
Constant Voltage Mode + Constant Current Mode
Range: 1200V / 160A
Resolution: 0.02V / 0.00256A
Accuracy: ± 1.0% of (Setting + Range)
Constant Voltage Mode + Constant Power Mode
Range: 1200V / 4000W
Resolution: 0.02V / 0.064W
Accuracy: ± 1.0% of (Setting + Range)
Turbo mode OFF / ON
Short/OCP/OPP Test Function
Maximum Current: 160A / 240A
Meas. Accuracy: ± 1.0% of (Reading + Range)
Short time: 100~10000mS;Continuous / 100~20000mS
Meas. Accuracy: NA / NA
OCP Time (Tstep): 100mS / 20mS
Meas. Accuracy: NA / NA
OPP Time (Tstep): 100mS / 20mS
Meas. Accuracy: NA /NA
BMS Test Mode OFF/ON (Turbor mode OFF) / OFF/ON (Turbor mode ON)
Short time: 100mS~10S/0.05~10mS / 100~1000mS/0.05~10mS
Meas. Accuracy: NA/±0.005mS / NA/±0.005mS
OCP Time (Tstep): 100mS/0.05~10mS;11~1000mS / 20mS/0.05~10mS;11~1000mS
Meas. Accuracy: NA/±0.005mS;±0.2mS / NA/±0.005mS;±0.2mS
Surge Test Mode
Surge current: 0~240A
Normal current: 0~120A
Surge Time: 10~2000ms
Surge Step: 1~5
MPPT Mode
Algorithm: P&O
Load mode: CV
P&O interval: 1000-60000mS
Resolution: 1000mS
Dynamic Mode
Timing:
Thigh & Tlow: 0.010~9.999/99.99/999.9/mS
Resolution: 0.0001/0.01/0.1/1mS
Accuracy: 1/10/100/1000 uS+50ppm
Slew rate: 0.01024~0.640A/uS / 0.1024~6.400A/uS
Resolution: 0.00256A/uS / 0.0256A/uS
Min. Rise Time: 25uS (Typ.)
Current:
Range: 0~16A / 16~160A
Resolution: 0.00026A / 0.00256A
Measurement
Voltage Read Back
Range (5 Digital): 0~120V / 120~1200v
Resolution: 0.00200V / 0.0200V
Accuracy: ± 0.025% of (Reading + Range)
Current Read Back
Range (5 Digital): 0~16A / 16~160A
Resolution: 0.000256A / 0.00256A
Accuracy: ± 0.05% of (Reading + Range)
Power Read Back
Range (5 Digital): 4000W
Accuracy: ± 0.06% of (Reading + Range)
General
Typical Short Resistance: 0.09375Ω
Maximum Short Current: 160A
Load ON Voltage: 1~250V
Load OFF Voltage: 0~250V
Power Consumption: 550VA
Dimension (HxWxD): 177mm x 440mm x 745mm
Weight: 29kg
Temperature: 0~40℃
Safety & EMC: CE
Option card: GPIB, RS232, USB, LAN are option, prices are same as 331XF
