Specifications:
Power: 3600W
Current: 0~240A
Voltage: 0~60V
Min.Operation Voltage: 0.6V@240A
-CC mode
Range: 0~24A/240A
Resolution: 0.4mA/4mA
Accuracy: ±0.1%
-CR mode
Range: 0.0041~0.25~15KΩ
Resolution: 0.0041mΩ/0.066mS
Accuracy: ±0.2%
-CV mode
Range: 6V/60V
Resolution: 0.1mV/1mV
Accuracy: ±0.05%
-CP mode
Range: 360W/3600W
Resolution: 6mW/60mW
Accuracy: ±0.5%
-Dynamic mode
+Timing
Thigh & Tlow: 0.050~9.999/99.99/999.9/9999mS
Resolution: 0.001/0.01/0.1/1mS
Accuracy: 1µS/10µS/100µS/1mS + 50ppm
Slew rate: 0.016A~1A/µS
0.16A~10A/µS
Resolution: 0.004/0.04A/µS
Accuracy: (5% of setting) ± 10µS
Min. Rise time: 24µS
+Current
Range: 24A/240A
Resolution: 0.4mA/4mA
Accuracy: ±0.1%
- Optional interface : GPIB, RS232, USB, LAN
