Power: 300W
Current: 0~3A; 0~12A
Voltage: 0~120V
Min.Operation Voltage: 1.5V at 12A
-CC mode
+Range: 0~3A; 0~12A
+Resolution: 0.05mA; 0.2mA
+Accuracy: 0.1%
-CR mode
+Range: CRL: 0.1Ω~1.2KΩ (60V); CRH: 0.2Ω~2.4KΩ
+Resolution: 166.666µS; 83.333µS
+Accuracy: ±0.2%
-CV mode
+Range: 12V/60V/120V
+Resolution: 0.2mV / 1mV / 2mV
+Accuracy: ±0.05%
-CP mode
+Range: 0~300W
+Resolution: 0.005W
+Accuracy: ±0.5%.
-LED mode
+Vo Voltage range: LEDL:12V / LEDM:60V / LEDH:120V
+Rd Resistance range:
LEDL:0.1~120 Ω at Vo-Vd = 0~1.2V
LEDL :1~1.2KΩ at Vo-Vd = 1.2~12V
LEDM:0.5~600Ω at Vo-Vd = 0~12V
LEDM:5~6KΩ at Vo-Vd = 12~60V
LEDH:1~1.2KΩ at Vo-Vd = 0~60V
LEDH:10~12KΩ at Vo-Vd = 60~120V
+Resolution: 16 bits
+Accuracy: Vd: ±(0.05% of setting + 0.1% of range); Rd: ±(0.05% of setting + 0.1% of range)
- Option (necessary) : 3302F- single channel mainframe ; 3305F- two channels mainframe ; 3300F- four channels mainframe
- Optional interface: GPIB, RS232, USB, LAN
