INPUT
Phase: 3Ø / 4 Wire+G
Voltage*1: 220/380Vac ±15%
Frequency: 47-63Hz
Max. Current*2: 170.7A
Power Factor: ≥0.94Max. Power
OUTPUT
Power (VA): 100kVA
Phase: 3Ø / 4 Wire + G
Voltage Ranges: PWF-M: 0-150V (L-N); PWF-L: 0-300V (L-N)
Voltage Resolution: 0.1V
Voltage Accuracy: 0.5% F.S.+4counts
Frequency Range : PWF-M: 300-800Hz; PWF-L: 45-500Hz
Frequency Resolution: 0.1Hz
Frequency Accuracy: ±0.02% F.S
Max. Current: 125A
Line Regulation: ≦ 0.5%
Load Regulation: ≦ 1%
Total Harmonic Distortion: ≦ 2%
Response Time: ≦ 1ms
MEASUREMENT
Voltage Range: 0V-300.0V
Voltage Resolution: 0.1V
Voltage Accuracy: 0.5% F.S.+4counts
Frequency Range: 45-800Hz
Frequency Resolution: ≦100Hz: 0.01Hz/ >100Hz: 0.1Hz
Frequency Accuracy: ±0.02% F.S.
Current Range(RMS): 0 - 9999A
Current Resolution(RMS): 0.1A
Current Accuracy(RMS): 0.5% F.S.+4counts
Power: Range: 0-120kW; Resolution: 0.1kW; Accuary: 1% F.S.+6counts
GENERAL
Efficiency: ≥85-90 % at Max. Power
HMI: Touch Screen, 7" Color TFT LCD
Overload Capacity: 125%/ 30min, 150%/10min; 200%/1min
Remote interface: Standard: RS-485/RS-232 Option: GPIB, Ethernet
Opertional Temperature: 0℃ ~+45℃
Humidity: 0~90% ( Non condensing )
Altitude: <1500m
Dimensions (H x W x D) : 1765x835x1040mm/ 69.5x32.87x40.94inch
*1 Please contact for other voltage specification.
*2 The rated input voltage is 380V
* All specifications are subject to change without notice.
