INPUT
Phase:1Ø / 2 Wire + G
Voltage: 196-264Vac
Frequency: 47-63Hz
Max. Current: 20A
OUTPUT
Power
(VA): 2500VA
(W): 2000W
Phase: 1Ø / 2 Wire + G
Voltage Ranges: 0-155Vrms / 0-310Vrms, user selectable
Voltage Accuracy: ±(1% of Setting + 0.1% F.S.)
Voltage Resolution: 0.1Vrms
Frequency: 40-500Hz
Frequency Accuracy: ±0.02%
Frequency Resolution: 0.1Hz
Max. Current (RMS): 20A/10A
Max. Current (Peak): 80A/40A
Total Harmonic Distortion (THD)
≤ 0.3% at 110V/220V, 50Hz, 60Hz
≤ 0.5% (Resistive Load)
Line Regulation: ±0.1V
Load Regulation: ≤ 0.07% F.S (Resistive Load)
Response Time: ≤ 300μs
Crest Factor: ≥ 3
Inrush Current: ≤ 4 time of max. output current ( RMS )
MEASUREMENT
Voltage Range: 0-420Vrms
Voltage Accuracy: ±(0.2% of Reading + 5 Counts)
Voltage Resolution: 0.1V
Frequency Range: 40.0-500.0Hz
Frequency Accuracy: ±0.1Hz
Frequency Resolution: 0.1Hz
Current Range (RMS): Hi: 2-24A/ Lo: 0.005-2.4A
Current Accuracy (RMS): ±(1% of reading +5 counts) at PF>0.2
Current Resolution (RMS): Hi: 0.01A/Lo: 0.001A
Peak Current Range: 0-90A
Peak Current Accuracy: ±(1% of Reading + 10 Counts)
Peak Current Resolution: 0.1A
Power Range: Hi: 200-2400W/ Lo: 0-240W
Power Accuracy: ±(2% of Reading + 10 Counts), at 40-500Hz
Power Resolution: Hi: 1W/Lo: 0.1W
GENERAL
Efficiency: ≥ 80% at Max. Power
Protection: OVP, LVP, OCP, OPP, OTP, RCP, Fan Fail and AMP Fail
Remote Interface Standard : RS-232/RS-485/PLC Remote IN & OUT
Option : Analog/Ethernet/USB
Over Current Foldback: Over Current Foldback
Output Sync Signal: ON, Event for Voltage or Frequency Change (Output signal 5V , BNC type)
Memories: 20 Memories, 4 Shortcuts
Operating Temperature: 0~40°C
Dimensions (HxWxD): 89×442×650mm/ 3.5×17.4×x25.6inch
Weight approx: 31.3kg / 69lbs
