INPUT
Phase: 3Ø / 3 Wire + G
Voltage: 380Vac ±15% (option: 480Vac)
Frequency: 47~63Hz
Max. Current*1: 839A
Power Factor: ≥0.85（Max. Power）
OUTPUT
Power (VA): 400kVA
Phase: 3Ø / 4 Wire + G
Voltage Ranges
Low(V): 0V-155.0V（L-N）
High(V): 0V-310.0V（L-N）
Voltage Resolution: 0.1V
Voltage Accuracy: 0.5% F.S.+4counts
Frequency Range *2: "Standard : 45-65Hz ; Option : 45~65Hz, 100Hz/120Hz/200Hz/240Hz/400Hz"
Frequency Resolution: 0.1Hz
Frequency Accuracy: ±0.02% F.S.
Max. Current (RMS)
Low(A): 1111.1A
High(A): 555.6A
Line Regulation: ≦ 1%
Load Regulation: ≦ 1% (Resistive Load)
Total Harmonic Distortion(THD) *3: ≦ 2% (Resistive Load)
Response Time: ≦ 2ms
MEASUREMENT
Voltage Range: 0V-310.0V
Voltage Resolution: 0.1V
Voltage Accuracy: 0.2% F.S.+4counts
Frequency Range: 45.0-500.0Hz
Frequency Resolution: 0.1Hz
Frequency Accuracy: ±0.02% F.S.
Current Range(RMS): 0 - 1111.1A
Current Resolution(RMS): 0.1A
Current Accuracy(RMS): 0.5% F.S.+4counts
Power Range: 0 - 400kVA
Power Resolution: 0.1kW
Power Accuracy: 1% F.S.+6counts
GENERAL
Efficiency: ≥0.85% at Max. Power
HMI: Touch Screen , 7" Color TFT LCD
Memories: 6 sets ( M1/M2/M3/M4/M5/M6)
Protection
Input : N.F.B, Over Voltage, Under Voltage,
Output : Over Voltage, Over Current, Reverse Current, Over Temperature
Remote Interface Standard : RS-232(SCPI) &RS-485(MODBUS)
Operational Temperature: 0℃~45℃
Humidity: 0~90% ( Non condensing )
Altitude: < 1,500m
Dimensions (H x W x D) *5:
2050 x 3880x 1539 mm
80.7 x 152.8 x 60.6 inch
Weight *5: 4450kg
*1 The max. current is based on rated input voltage of 380V.
*2 For frequency option, please contact us for output power characteristic curve
*3 When the output voltage is at Low : 90 - 140V or High 180 - 280V with load power factor of 1
*4 Dimensions and weight are for input voltage 220/380V. Please contact us for dimensions and weight for other input voltage.
* All specifications are subject to change without notice. The specifications are tested at ambient temperature of 25℃ ± 5℃
