Output voltage range: 0‐120V
Output current range: 0‐5Arms (15A peak)
Output power: 0.0001VA~500VA (1500VA peak)
Turn ratio range: 1‐30000
Ratio measurement:
30000:1 or 45000:5
accuracy: ±0.05% Typ.; ±0.1% Gur.
Test Points selected: Automatic test of all points according to standard requirement
Phase measurement:
accuracy: 1min Typ. 3min Gur.
resolution:0.01min
Current measurement range: 0‐15 A (auto ranging) ; accuracy: ±0.05%Typ ±0.1% Gur.
Voltage measurement range: 0‐120V (auto ranging); accuracy: ±0.05%Typ ±0.1% Gur.
Polarity: Yes
Winding Polarity Test:Yes (Phase between ±45°)
Winding ratio accuracy: 0.1% or 1 turn
Winding resistance measurement
range: 0.05~1000Ω
accuracy: ±0.05%±1mΩ Typ.; ±0.1%±1mΩ Gur.
Temperature Compensation: ‐20 ℃‐120 ℃
Communication port: USB
Dimension (WxHxD): 470mmx200mmx245mm
Weight: 10kg/14kg
Main supply:
110‐240Vac/50‐60Hz (nominal)
90‐260Vac/45‐65Hz (permissible)
Max.2000VA, Standard AC socket 60320
Operation temperature: ‐10 ℃‐50 ℃
Storage temperature: ‐25 ℃‐70 ℃
Humidity: Relative 5% up to 95%, no‐condensation
