AC Current outputs
Control: Independent control of amplitude, frequency and phase angle
Range: 6×15A / 3×30A / 1×60A
Accuracy: error < 0.08 % rd. + 0.02 % rg. guar.; error < 0.03% rd. + 0.02 % rg. typ.
Resolution: 1mA
Output power: ≥210VA (at 30A, LN); ≥105VA (at 15A, LN)
Output response time: <100µs
Distortion (THD%): <0.05% type.,<0.1% guar., at >0.5A
Frequency- Amplitude characteristic: ≤± 0.1%~± 0.5% (1Hz~1kHz)
Output time: continuous (<10A/channel); >70s (10~20A/channel); >15s (≥20A/channel)
Operation indication: Overload, distortion, open circuit, over heat
AC voltage outputs
Control: Independent control of amplitude, frequency and phase angle
Fourth voltage (Uz): 0~300V
Power
4-phase ac(L-N): 4×75VA typ., at 300V/ 4×50VA guar., at 300V
3-phase ac(L-N): 3×100VA typ., at 300V/ 3×85VA guar., at 300V
1-phase ac(L-L): 1×200VA typ., at 600V/ 1×170VA guar, at 600V
Accuracy: error < 0.08 % rd. + 0.02 % rg. guar./ error < 0.03% rd. + 0.02 % rg. typ.
Resolution: 1mV(<30V), 10mV(30V~300V)
Output response time: <100µs
Distortion (THD%): <0.05% type., <0.1% guar., at 30V-300V
Frequency- Amplitude characteristic: ≤± 0.1%~± 0.5% (1Hz~1kHz)
Frequency
Sine signal: DC, 0.001Hz~1000Hz
Accuracy: 0.3ppm
Resolution: 0.001Hz
Output characteristic: Can simulate 2nd -20th harmonic or DC
Phase angle
Range: -360°~+360°
Accuracy: ±0.05° type., ±0.1° guar.
Resolution: 0.001°
DC Current outputs
Range: 3×±0~10A / 1×±0~30A
Accuracy: ±5mA (0.2A~1A) ±0.5% (1A~10A)
Resolution: 1mA
Output power: 3×100W at 10A / 1×300W at (30A 10V)
DC voltage outputs
Range: 4×±0~300V / 1×±0~600V
Accuracy: ±50mV (2V ~10V), ±0.5% (10 ~300V)
Resolution: 10mV
Output power: 100W at 300V
Operation temperature: 0~+50℃
Storage temperature: -25~+70℃
Relative humidity: 5~95% non - condensing
Dimension (W×H×D): 256mm × 110mm× 395mm
Weight: 8.6 kg
