Pintech PA-8033 ການສະຫນອງພະລັງງານ DC (195VA)
Power Transformer: E.I. Type Transformer
Max. Continual Output Power: 195VA
Max. Raised Temperature: < 45°C
Independent Output: 0~32V/0~3A x 2, 5V Fixed / 0~3A; Triple Output
Constant Voltage Characteristic
Regulation: Line <0.05%+3mV, Load<0.05%+5mv
Ripple & Noise: < 0.4mVrms
Temperature coefficient: < 300PPM/°C
Constant Current Characteristic
Regulation: Line<0.2%+2mA, Load<0.2%+3mA
Ripple & Noise: < 2.5mArms
5V Fixed Output
Regulation: Line< 5mV，Load<10mV
Ripple & Noise: < 1.5mVrms
Voltage Accuracy: 5V ± 0.25V
Max. Output Current: 3A
Tracking Operation
Parallel Regulation: Line< 0.01%+3mV, Load< 0.01%+5mV
Series+and-Supply Regulation: Line< 0.01%+3mV, Load< 0.01%+5mV,Slave tracking error <0.5%+digital of the master 2
Series Single Supply Regulation: Line<0.01%+5mA, Load<300mV
Display
Voltage: 3 Digits 0.56" Green LED
Current: 3 Digits 0.56" Red LED
Accuracy: 0.1% + 2 Digits
General
Power supply: ACV 115/230 ± 10%, 50/60Hz
Dimension ( W x H x D): 230 x 170 x 310 mm
Weight: 7.9kg
