ERTICAL
Number of Channels 4
Input connectors SMA
Bandwidth (-3 dB) 1 GHz
Rise time (calculated) 350 ps
Resolution 8 bits (12 bits with software enhancement)
Input impedance 50 Ω ±2%
VSWR < 1.5:1 DC to 1 GHz typical over full bandwidth of scope
Input coupling DC
Input sensitivity 20 mV/div (10 vertical divisions)
Input ranges ±100 mV
DC accuracy ±3% of full scale
Overvoltage protection ±2 V (DC + Peak AC)
HORIZONTAL
Sampling rate (real time 1 Channel) 5 GS/s
Sampling rate (real time 2 Channels) 2.5 GS/s (using A+C, A+D, B+C, B+D)
Sampling rate (real time 4 Channels) 1.25 GS/s
Sampling rate (cont. USB streaming) 1 MS/s in PicoScope software. >10 MS/s using supplied SDK (PC-dependent)
Buffer memory 1 GS
Waveform buffer (no. of segments) 1 to 10,000
Timebase accuracy ±5 ppm
DYNAMIC PERFORMANCE (typical)
Crosstalk 100:1 DC to 100 MHz
30:1 100 MHz to 1 GHz
Step response ±3% after 3 ns, typical
Noise <0.5 mV RMS
TRIGGER
Basic trigger modes Rising, falling
