Frequency range 300 kHz to 6.0 GHz
Frequency setting resolution 10 Hz
Frequency accuracy 10 ppm max With ambient of 23 ±3 °C
Frequency temperature stability ±0.5 ppm/ºC max Over the range +15 °C to +35 °C
Harmonics –20 dBc max With test power set to < –3 dBm
Non-harmonic spurious –40 dBc typical
Phase noise (10 kHz offset)
0.3 MHz to 1 GHz: –90 dBc/Hz
1 GHz to 4 GHz: –80 dBc/Hz
> 4 GHz: –76 dBc/Hz
Test signal power
< 10 MHz: –3 to –20 dBm
10 MHz to 4 GHz: +6 to –20 dBm
> 4 GHz: +3 to –20 dBm
Power setting resolution 0.1 dB
Power setting accuracy ±1.5 dB
Reference input frequency 10 MHz ±6 ppm
Reference input level 0 ±3 dBm
Reference output level 0 ±3 dBm
Miscellaneous
Controlling PC data interface USB 2.0
Support for third party test software Dynamic Link Library (DLL) as part of user interface software
External dimensions (mm) 286 x 174 x 61 (L x W x H) excluding connectors
Weight 1.85 kg
Temperature range (operating) +15 °C to +35 °C
Temperature range (storage) –20 °C to +50 °C
Humidity 80% max, non-condensing
Vibration (storage) 0.5 g, 5 Hz to 300 Hz
Power source and current +12 to +15 V DC, 22 W
Power source connector 5.5 mm diameter hole, 2.1 mm diameter centre contact pin.
Centre pin is positive.
Host PC requirements Microsoft Windows 7, 8 or 10
2 GB RAM or more
Safety Conforms to EN61010-1:2010 and EN61010-2-030:2010
