Number of channels: 4
Bandwidth: DC to 16 GHz
Vertical sensitivity: 10 mV/div to 250 mV/div
Input voltage: ±800 mV
ADC resolution: 12 bits
Coupling: DC
Connector type: SMA female
Base time range (real-time sampling): 10 ns/div to 1000 s/div
Maximum sampling rate (real-time): 500 MS/s
Record length (real-time): From 50 kS/channel to 250 kS/channel for 1 channel, up to 125 kS/channel for 2 channels, up to 50 kS/channel for 3 and 4 channels
Integrated marker features: Absolute measurement, delta measurement, voltage, time, frequency, and slope
Integrated automatic measurements
FFT mode.
