PICO PicoScope 9402-16 oscilloscope ດິຈິຕອນ (2 CH, 16 GHz, 500 MS/s)

Number of channels: 2

Bandwidth: DC to 16 GHz

Vertical sensitivity: 10 mV/div to 250 mV/div

Input voltage: ±800 mV

ADC resolution: 12 bits

Coupling: DC

Connector type: SMA female

Base time range (real-time sampling): 10 ns/div to 1000 s/div

Maximum sampling rate (real-time): 500 MS/s

Record length (real-time): From 50 kS/channel to 250 kS/channel for 1 channel, up to 125 kS/channel for 2 channels

Integrated marker features: Absolute measurement, delta measurement, voltage, time, frequency, and slope

Integrated automatic measurements

Mode: FFT
